NICE Receiver
NICE Receiver - Image 2
Nice

SKU: OXIFM*-1

NICE Receiver

Pre-Wired Universal 433.92 MHz

433

£94.93 – £134.06 exc VAT

  • NICE Receiver Pre-Wired Universal 433.92 MHz
  • The complete line of receivers with opera system functions, suitable with all installation requirements
  • Universal prewired, or use with all types of control unit, for the control of any automation, lighting or irrigation system or other electric circuits
  • Maximum flexibility: up to 1024 transmitters can be memorised
  • Convenient and Practical: the inclusion of a transmitter in the OXIT/OXITFM, OX2T/OX2TFM and OX4T receivers allows radio codes to be accessed by means of the O-Box multi function interface even when in inaccessible positions
  • OXIT/OXITFM, OX2T/OX2TFM and OX4T receivers can be used as signal repeaters to increase the operating distance between transmitters and other ONE series receivers
  • Secure Use, thanks to the 3 password-protected levels
  • 2 or 4 Channels

The O-Box and dedicated software applications for PC and PDA allow quick programming of receivers and transmitters, management of code list, creation of individual installation databases.



Code
OX2
OX2T / OX4T
Reception frequency (MHz)
433.92
433.92
Transmission frequency (MHz)
-
433.92
Input impedance (Ohm)
52
52
Sensitivity
-108 dBm
>0.5 u V for successful signal
Encoding
O-Code, FloR, Flo
O-Code, FloR, Flo
Number of channels
2
2
Relay contact
max. 0.5 A 50 V (NO)
max. 0.5 A 50 V (NO) / 5A - 250V
Power supply
12 to 28 VDC/VAC
12 to 28 VDC/VAC / 110 - 240 VAC 50/60Hz
Draw
80mA
80mA
Protection class
IP30
1P 30 / IP 44 (with undamaged case)
Dimensions (mm)
58x86x22 h
58x86x22 h / 128x112x43 h
Weight (g)
55
55 / 260

Document Downloads
