1 or 2 button - Flush or Surface

£624.65£665.66 exc VAT

  •  4000 series modules in a new 316 grade stainless steel matt finish
  •  1  button up to 12 button kits available (surface or flush )
  • Expandable up to 50 call buttons using combination of additional 4000 series modules
  • All have facility to divert to additional numbers (if busy or unanswered) – 1 primary & 3 diverts
  • DDA compliant voice annunciation and call progress LED’s
  • The 4G GSM intercom module is able to connect to 2G, 3G & 4G networks (for global use)
  • 1000 dial to open numbers (can be assigned with an access level)
  • 32 temporary dial to open numbers (programmable from 1-255 hours)
  • 1000 user integrated proximity access
  • 1 programmable call button timebands
  • Up to 10 programmable access control time bands
  • Up to 10 programmable free access time bands
  • Up to 10 programmable access levels
  • Automatic time correction feature including daylight saving adjustments
  • Programming by SMS, via the Videx smart phone SMS Wizard Apps, the GSMSK PC software or the new ‘over the air’ feature
  • Push to exit input and dry contact relay (C, NO & NC)
  • 2 Auxiliary inputs and 2 Auxiliary outputs
  • Micro USB connection (for ease of programming using GSMK software)
  • RS485 bus connection (for networking with Art. 4903 keypad and/or 4850R off board proximity reader or for ease of programming using GSMSK software)



2G, 3G, & 4G
Lock output
Dry contact relay (C, NO, NC)
Auxiliary outputs
2 x Open collector
Auxiliary inputs
Dial to open numbers
Up to 1000
Temp dial to open numbers
Up to 32
Programmable timebands
1 x call button timebands, 10 x access control timebands, 10 x free access timebands
Divert calls per button
1 to 3 numbers each
Power input
Programming methods
SMS Text or Videx smartphone apps , GSMSK PC software or remotely via 'over the air' feature
USB connection
micro USB
RS485 connection
Yes = A, B. & OV
Event logging
up to 4000 events
PSU model
HDR-15-12 slim line 12Vdc psu
434 (5m cable)
Amplifier module
4810-0/4G, 4810-1/4G & 4810-2/4G depending on GSM kit)
Module finishes
Matt 316 grade stainless steel
appropriate 4000 series or flush back box
up to 50 buttons (combination of modules 4042,4043,4044 & 4045)
