SKU: VER10B- VER13B KIT

CAME VER PLUS

VER10 (1000N) & VER13 (1300N)

24

£274.20£327.60 exc VAT

  • Operator for sectional or up-and-over garage doors
  • Maximum door surface up to 21 m²
  • Silent & reliable
  • Premium Belt Guide
  • Fastened directly onto the drive guide
  • 30 cycles/hour
  • 24 V DC systems to ensure greater safety & reliability
  • Control board with separate & removable terminal blocks
  • External display buttons for easier start ups and diagnosis
  • Save up to 250 different users
  • Radio programming Rolling code & integrated Key Code (Twir)
  • Can manage CAME keypads via the R800 card or connect transponder selectors via R700 accessory
  • Display for programming & viewing features
  • Encoder with obstacle detection
  • Can operate in emergency mode in case of power outage
  • External pull cord release to fit onto the doors lock and handle system
  • Easy installation
  • Adaptable in-line or at 90°
  • Devices developed for connection in the cloud, via CAME Connect.

VER10B-KIT – 1000N – for door up to 18m²

VER10B-KIT – 1300N  – for door up to 21m²

Models
801MV-0010
801MV-0020
Protection rating (IP)
40
40
Power Supply (V - 50/60 Hz)
230 AC
230 AC
Power supply to motor (V)
24 DC
24 DC
Absorption (A)
10 Max.
10 Max.
Power (W)
180
280
Duty/cycle (%)
50
50
Cycles/Hour
30
30
Operating temperature (°C)
-20 ÷ +55
-20 ÷ +55
Manouvering speed (m/min)
7 Max
7 Max
